How to Find Displacement from a Velocity-Time Graph

Understanding how to extract displacement from a velocity-time graph is a fundamental skill in physics that bridges abstract mathematical concepts with tangible motion. This graph is a powerful visual tool, plotting an object's velocity (on the vertical axis) against time (on the horizontal axis). The total area enclosed between this curve and the time axis directly represents the object's net displacement over that time interval. This principle works because velocity is the rate of change of displacement; integrating velocity over time (finding the area under the curve) mathematically yields the total change in position. Mastering this technique allows you to analyze complex motion—like a car accelerating, braking, and reversing—without needing a single equation of motion.

Reading the Graph: The Foundation

Before calculating, you must accurately interpret the graph's components. The slope of the velocity-time graph at any point gives the object's acceleration. A horizontal line (zero slope) means constant velocity (zero acceleration). An upward sloping line indicates positive acceleration (speeding up in the positive direction or slowing down in the negative). A downward slope indicates negative acceleration (deceleration or acceleration in the negative direction).

The position of the line relative to the time axis is critical. Areas above the time axis represent positive displacement (motion in the defined positive direction). Areas below the time axis represent negative displacement (motion in the opposite direction). The net displacement is the algebraic sum of all these areas. A line on the axis itself means zero velocity, so the object is at rest, contributing no area.

Calculating Area: The Core Method

The displacement is the signed area under the velocity-time curve between two times, t₁ and t₂. You calculate this by breaking the graph into simple geometric shapes—rectangles, triangles, and trapezoids—whose areas are easy to compute. The formula for each shape's area must be applied with the correct sign based on its position above or below the axis.

1. Rectangular Sections (Constant Velocity)

For a horizontal line segment at velocity v lasting from time t₁ to t₂, the shape is a rectangle.

• Area = base × height = (t₂ - t₁) × v
• If v is positive (above axis), the area is positive.
• If v is negative (below axis), the area is negative.

2. Triangular Sections (Constant Acceleration from Rest)

For a straight, sloped line starting or ending at zero velocity, the shape is a triangle.

• Area = ½ × base × height
  • Base is the time interval (t₂ - t₁).
  • Height is the velocity at the peak of the triangle (the final velocity if starting from zero, or the initial velocity if ending at zero).
• Determine the sign based on whether the triangle is above (positive) or below (negative) the time axis.

3. Trapezoidal Sections (Constant Acceleration with Non-Zero Start/End Velocity)

For a straight, sloped line that does not cross the time axis, the shape is a trapezoid.

• Area = ½ × (sum of parallel sides) × height
  • The parallel sides are the initial velocity (vᵢ) and final velocity (v_f) at the segment's endpoints.
  • The height is the time interval (Δt).
• Formula: Area = ½ × (vᵢ + v_f) × Δt
• The sign of the entire area follows the sign of the velocities. If both vᵢ and v_f are positive, the area is positive. If both are negative, the area is negative. If one is positive and one negative, the trapezoid crosses the axis, and you must split it into a triangle and rectangle or calculate the net area carefully.

4. Irregular Curves

For non-linear graphs, you must approximate the area using many small rectangles (a method akin to numerical integration). In introductory physics, graphs are typically composed of straight lines, making the geometric approach exact.

The Critical Step: Handling Direction and Net Displacement

The most common error is forgetting that displacement is a vector quantity—it cares about direction. You cannot simply add absolute areas. You must assign a positive sign to areas above the axis and a negative sign to areas below. The net displacement is the sum of all these signed areas.

Example: An object moves forward (positive velocity) for 4 seconds, covering an area of +8 m. It then moves backward (negative velocity) for 2 seconds, covering an area of -3 m. Its net displacement is (+8 m) + (-3 m) = +5 m from the starting point. The total distance traveled would be 8 m + 3 m = 11 m, but displacement is only 5 m in the positive direction.

Step-by-Step Worked Example

Consider the following velocity-time graph description:

• From t=0 to t=2 s: velocity increases linearly from 0 m/s to 4 m/s (a triangle above the axis).
• From t=2 s to t=5 s: velocity is constant at 4 m/s (a rectangle above the axis).
• From t=5 s to t=7 s: velocity decreases linearly from 4 m/s to -2 m/s (a trapezoid that crosses the axis).
• From t=7 s to t=9 s: velocity is constant at -2 m/s (a rectangle below the axis).

Step 1: Identify and Label Each Segment

• Segment A (0-2 s): Triangle, above axis.
• Segment B (2-5 s): Rectangle, above axis.
• Segment C (5-7 s): Trapezoid, crosses axis.
• Segment D (7-9 s): Rectangle, below axis.

Step 2: Calculate Signed Area for Each Segment

• Segment A: Triangle. Base = 2 s, Height = 4 m/s. Area = ½ × 2 × 4 = +4 m.
• Segment B: Rectangle. Base = 3 s, Height = 4 m/s. Area = 3 × 4 = +12 m.
• Segment C: Trapezoid from 4 m/s to -2 m/s over 2 s. This crosses the axis. Best to split it.
  • Part C1 (5-6 s): Triangle from 4 m/s to 0 m/s. Base=1s, Height=4 m/s. Area = ½ × 1 × 4 =

+2 m.

• Part C2 (6-7 s): Triangle from 0 m/s to -2 m/s. Base=1s, Height=2 m/s. Area = ½ × 1 × (-2) = -1 m.
• Total for Segment C: +2 m + (-1 m) = +1 m.
• Segment D: Rectangle. Base = 2 s, Height = -2 m/s. Area = 2 × (-2) = -4 m.

Step 3: Sum the Signed Areas for Net Displacement Net Displacement = (+4 m) + (+12 m) + (+1 m) + (-4 m) = +13 m.

The object ends up 13 meters from its starting point in the positive direction. The total distance traveled would be 4 m + 12 m + (2 m + 1 m) + 4 m = 23 m, but the displacement is only 13 m.

Conclusion

Finding displacement from a velocity-time graph is a powerful application of the fundamental relationship between velocity, time, and position. By recognizing that the area under the curve represents displacement, and by carefully accounting for the sign of each area segment, you can accurately determine an object's change in position. This method transforms a complex motion into a series of simple geometric calculations, providing a clear and intuitive understanding of how velocity over time dictates where an object ends up. Mastering this technique is essential for solving a wide range of kinematics problems and building a strong foundation in physics.
